Make: Hillman
Model: Imp post-1969 vehicles 2-door (1969-1976).
Description:
Roll cage number C003. 6 point bolt-in cage. Clears normal trim and dashboard. Rear cage mounts to the floor and rear wheel arches. Rear available with seat belt mount (for standard lap and shoulder 3 point seatbelt). Seat belt mount is not a harness bar.
Front options:
RBC003 3SSS – Front roll cage for universal door bars.
Must be used with a rear roll cage.
Rear options:
- RBC003 5SSS – Rear cage, single fixed diagonal. Rear door pockets may need to be removed for the installation of this rear cage.
May be used alone.
- RBC003 5SSS/B – Rear cage, single fixed diagonal and seatbelt mount (see the main description of seat belt mount) Rear door pockets may need to be removed for installation of this rear cage.
May be used alone.
- RBC003 5SSS-HB – Rear cage, single fixed diagonal, and harness bar. Rear door pockets may need to be removed for the installation of this rear cage.
May be used alone.
- RBC003 5SSS/B-HB – Rear cage, single fixed diagonal, harness bar, and seatbelt mount (see the main description of seat belt mount) Rear door pockets may need to be removed for installation of this rear cage.
May be used alone.
- RBC003 5SXS – Rear cage, cross diagonal, and harness bar. Rear door pockets may need to be removed for the installation of this rear cage.
May be used alone.
- RBC003 5SXS/B – Rear cage, cross diagonal, harness bar, and seatbelt mount (see the main description of seat belt mount). Rear door pockets may need to be removed for the installation of this rear cage.
May be used alone.
Door Bar options:
- Â Â RB00A1 – Universal door bar 38/38mm.
One required per side. Must be used with the front and rear roll cage.
Technical Specification:
- Finished roll cage provided with black powder coat paint finish unless specified otherwise.
- Other colours available: grey, blue, silver, white and red.
- Roll cage can be provided unpainted by special request.
Independently Certified: MSA/FIA homologated. Certificate available from MSA, Telephone 01753 765000.
